Head 20m - 120m

DIVE-HAX-Turbine for Medium Head Applications

The DIVE-HAX-Turbine is a half-axial turbine with electronic regulation for heads up to 120m.

The generator of the DIVE-HAX is directly connected with the turbine shaft. Due to the patented DIVE-sealing, the whole system is permanently flood-save. The generated currency is prepared for grid feed-in by electronic inverters.






1 Runner with fix runner blades

2 Control unit for regulation and as shut-off valve

3 Permanent magnet generator

4 Draft tube

5 Power plant control and grid conditioning



maintenance-free runner

minimal vibrations

no de-sanding neccessary

double regulation by speed variation

overview of the advantages of a DIVE-Turbine
